LUTETIA SMOKE GENERATOR. To be positioned beside the cooker.

Dimensions: Width : 1 500 mm Depth : 1 400 mm Height : 3 200 mm Height, necessity of 4000 mm for access and accessories. Full Stainless steel construction. Capacity per cooker: 1 trolley Europe type (1000*1000*2050 mm) not included. Electrical heated. Dry cook and drying. Smoking with liquid smoke generator (see option).(not included) Steam cook with steam generator (see option).(not Included) No need if the factory is equipped with its own factory steam network. Maximum temperature: 120°c in dry mode. Equipped with: *Delta Plc and Delta 10” touch screen. * Ambient, core and surface temperature recording through Nanodac system. * Steam and/or smoke extractor. * Stainless steel floor 5 mm. * One front door. *One two speed ventilation motor. * Automatic cleaning system. * Humidity control. One complete stainless steel control panel including power. Electricity: 31 kW + 24 kW if steam generator. 400 v at 60 hz. Important safety point: The main circuit breaker on the main line going from your control board tothe control panel of the cooker has to be equipped with a voltage release. Compressed air: 6 bars, 0,5 m3 per hour. Water: 3 bars
